SAIC MG 6 - Engine Compartment Fuse Box

EmergencyInformation
EngineCompartmentFuseBox
F L 7 F L 8
F 1
F 3
F 5
F 7
F 9
F 2
F 4
F 6
F 8
F 1 0
F L 9
F L 1 0 F L 1 1 F L 1 2
F L 2
F L 1
F L 3 F L 4 F L 5 F L 6
CheckingorRenewingFuses
1T urnofftheignitionswitchandallelectrical
equipment.Disconnectthebatterycable.
2Pressthebuckle(seeillustration)toremovethe
cover .
3Checkifthereisanyblownfuse.
4Forablownfuse,replaceitwithsamerating.
FuseSpecication
Code
RatingFunction
F1
15A
T urboBoostControlSolenoidValve,
LambdaSensor-DownSttream,Valve
-PurgeControl,NeutralGearSensor ,
Relay-SecondaryAirPump,Valve-
SecondaryAir
F220AInjectors,IgnitionCoils,ECU-Engine
F315ALambdaSensor-UpSttream,
F45A
Relay-Motor-CoolingFan,Relay
-A/CClutchCompressor,Relay-
Starter,Relay-EVP ,Switch-Intelligent
Stop/StartSystem,HFMsensor,Neutral
GearSensor
F5
10AECU-Engine
F615A
Relay-FrontFogLamps,FrontFog
Lamps/DaytimeRunningLamp
