InstrumentsandControls
ElectronicSteeringColumnLock(ESCL)/
SteeringAngleSensor(SAS)Warning-Red
Thewarninglightisusedtoindicatetothedriverthata
faultexistsinelectronicsteeringcolumnlocksystemor
steeringanglesensor .
IfESCLhasafault,thewarninglightwillilluminateandthe
messagecenterwilldisplaySteeringSystemFault.
SeekanMGAuthorisedRepairerurgently.
IfSAShasafault,themessagescreenwilldisplaySAS
Fault.IfSASisnotcalibrated,themessagescreenwill
displaythepromptmessageSASUncalibrated.Seek
anMGAuthorisedRepairerurgently.
EPBStatus/AutoHoldStatusWarning-Red/
Green
*
WhentheEPBisengagedtheredwarninglightilluminates.
IfafaultoccurswiththeEPBswitchtheredlightwillash.
WhenAutoHoldsystemisfunctioning,thelamp
illuminatesgreen.
EPBFaultWarning-Y ellow
Thewarninglightisusedforinformingthedriveraboutan
electronicparkingbrakefaultorelectronicparkingbrake
intodiagnosisstate.Atthemoment,thewarninglightwill
illuminate,accompaniedbyanaudiblealarm.
SystemFaultWarning/AlarmStatusWarning
-Y ellow/Red
Thewarninglightcanilluminateeitheryelloworgreen.
Thelightisusedtoindicatetothedriverthestatusof
anynon-tell-talewarningsthatareactivewhentheignition
isinpositionⅡ.Thislampilluminatedineitherredor
yellowdependinguponwhatwarningscurrentlyexist.The
lampisilluminatedredifaredwarningexists.Thelampis
illuminatedyellowifayellowwarningexists.Ifbothredand
30
