100 • Service Mode SAM4S ER-230EJ Manual
Use the PC Utility to Convert the Image
See page on 90 for detail.
Copy the Images to an USB memory
The PC Utility will create two image files:
USERPRE.IMG
USERPOST.IMG
They will be located in your PC at:
C:\MyDocuments\eSpresso\Storename\register name\IMAGE
Copy the mages to the following path on your USB memory:
USB\\ ER-230EJ \Storename\IMAGE
Important: In the path: C:\MyDocuments\eSpresso\Storename, the store name is the
name you have defined as the store in the PC Utility.
Note: You must use the same store name in the ER-230EJ ECR at “Store name” of
“SYSTEM” of the “Options Programming” Note that the default store name is
“STORE001”.
Saving Images from an ER-230EJ to an USB memory
1. Insert the SD card in the register’s USB slot.
2. Move to the SERVICE MODE.
3. From the Service Mode menu, select “7.PROGRAM BACKUP”.
4. From the PROGRAM BACKUP menu select “2.USB”.
5. From the USB menu select “4.IMAGE SAVE”.
6. The message “SUCCESS !” will display on the LCD.
Loading the Images by USB memory
7. Insert the SD card in the register’s USB slot.
8. Move to the SERVICE MODE.
9. From the Service Mode menu, select “7.PROGRAM BACKUP”.
10. From the PROGRAM BACKUP menu select “2.USB”.
11. From the USB menu select “5.IMAGE LOAD”.
12. The message “SUCCESS !” will display on the LCD.
