SAM4S ER-230EJ Manual Service Mode • 81
Define Port (SERIAL, USB)
Serial Port Setting
1. At the SERVICE MODE, press 5 and CASH for serial programming. The
port selection screen displays:
DEFINE PORT
1. PORT 1
DEFINE PORT
1. PORT 1
2. PORT 2
3. USB TYPE
4. SCAN
2. Enter the digit (1-4) corresponding to the port you wish to program. Press the
4 and CASH to print Port1&Port2 settings. The appropriate PORT
PROGRAM screen displays:
3. Press the ↑ key and the ↓ key for selecting value. Press CASH to confirm
the option value and return menu.
PORT 1
1. BAUD RATE [9600]
2. PARITY [NONE]
3. DATA BITS [8BITS]
4. STOP BITS [1BIT]
5. DEVICE [NONE]
6. PRINTER [NONE]
7.DISPLAY [EPSON]
8. KP START LINE [0]
9. KP END LINE [7]
10 . SLIP START LINE [0]
4. Press the CLEAR key to finalize and return to the DEFINE PORT screen.
