SAME SOLARIS 55 User Manual

SECTION III USE
Behaviour of the oil flow in the hydraulic circuit connecting the
couplers and the actuator cylinders on the implement.
A - Oil pressure to cylinder - LIFTING
B - Oil pressure to cylinder – LOWERING
57
WARNING: DURING THE IMPLEMENT HITCHING AND UNHITCHING
OPERATIONS GREAT CARE MUST BE TAKEN TO ADVOID SERIOUS
INJURY TO YOURSELF AND OTHERS. WHENEVER USING SUP-
PORTS FOR THE IMPLEMENT, MAKE SURE THEY ARE SUITABLE
AND SUFFICIENTLY STRONG. NEVER USE CONCRETE BLOCKS,
BRICKS OR WOOD FOR SUPPORT. THEY CAN COLLAPSE EVEN
UNDER LIGHT LOADS. DON’T ALLOW PEOPLE TO STAY NEARLY.
AB

SAME SOLARIS 55 Specifications

General

Power	55 hp
Transmission	Mechanical
PTO Power	48 hp
PTO Speed	540/1000 rpm
Gearbox	12
Hydraulic Remotes	2
Engine Type	Diesel
