SECTION VI ELECTRICAL SYSTEM
Connector for connection to front wiring loom
Connector for connection to rear wiring loom
165
DANGER: WHEN HANDLING BATTERIES:
- AVOID BREATHING IN FUMES PRODUCED BY THE ACID SOLU-
TION (if the acid is accidentally swallowed, drink plenty of water or
milk, then drink beaten eggs or vegetal oil; seek medical attention im-
mediately)
- USE THE APPROPRIATE PROCEDURE WHEN CHARGING
- CLEAN ALL PARTS WHERE ACID SOLUTION MIGHT HAVE
SPILLED. IF IT SPILLS ON THE HANDS, NEUTRALIZE IT WITH HY-
DRATED LIME OR SODIUM BICARBONATE. IF IT HITS THE EYES,
RINSE REPEATEDLY FOR 10-15 MINUTES, THEN SEEK MEDICAL
ATTENTION IMMEDIATELY.
12
15
11
10
13
14
6
3
5
2
1
4
8
7
9
RV 1
AL CABLAGGIO ANTERIORE
TO FRONT SIDE WIRING
DIPPED H.
LIGHTS
DIPPED H.
LIGHTS
FULL BEAM H.
LIGHTS
HORN
STOP ELETTR.
STOP ELETTR.
FUEL PUMP
WATER TEMP.
RPM INDICATOR
GENERATOR
FUEL LEVEL
FUEL RESERVE
WATER TEMP.
MOTOR OIL
PRESS.
AIR FILTER
ANABBAGL.
ANABBAGL.
ABBAGLIANTI
AVV. ACUSTICO
EV. STOP
EV. STOP
POMPA GAS.
°C ACQUA
W CONTAGIRI
GENERATORE
LIVELLO GAS.
RISERVA GAS.
°C ACQUA
P. OLIO MOT.
FILTRO ARIA
1
2
3
4
5
6
7
8
B 0.5
9
10
11
12
13
14
15
M 0.5
R 0.5
VN 0.5
C 0.5
L 0.5
LB 0.5
ZB 0.5
RV 1
A1
A1
Z1
V 1.5
HN 1
H1
N1
V1
HG
FARO LAVORO
WORK LIGHTS
AL CABLAGGIO POSTERIORE
TO BACK SIDE WIRING
RIGHT POSITION
LEFT POSITION
+ STOP LIGHTS
RIGHT DIRECTION
LEFT DIRECTION
P.T.O.
HAND BRAKE
DIFF.
D.T.
10
7
1
4
3
6
9
12
2
5
11
8
1
2
3
4
5
6
7
8
G1
9
10
11
12
GN
HR 1
A1
AN 1
GV 1
RN 1
AR 1
AB 1
POSIZIONE DX
POSIZIONE SX
+ LUCI STOP
DIREZIONI DX
DIREZIONI SX
P.T.O.
FR. A MANO
DIFF.
D.T.
1
2
