SECTION III USE
Example connection and operation of a double-acting cylinder
(Turnover of reversible plough)
When the auxiliary service control valves are not in use, the control levers
must always in be in the neutral position
58
4
4
3
WARNING: DIESEL FUEL OR HYDRAULIC FLUID UNDER PRES-
SURE CAN PENETRATE THE SKIN OR EYES AND CAUSE SERIOUS
PERSONAL INJURY, BLINDNESS OR DEATH. FLUID LEAKS, UNDER
PRESSURE, MAY NOT BE VISIBLE. USE A PIECE OF CARDBOARD
OR WOOD TO FIND LEAKS. DO NOT USE YOUR BARE HAND. WEAR
SAFETY GOGGLES FOR EYE PROTECTION. IF ANY FLUID IS IN-
JECTED INTO THE SKIN, IT MUST BE SURGICALLY REMOVED
WITHIN A FEW HOURS BY ADOCTOR FAMILIAR WITH THIS TYPE OF
INJURY.
