SAME SOLARIS 55 User Manual

SECTION VIII TECHNICAL SPECIFICATIONS
Clutch
The clutch is of the 2-stage type with one plate for the main drive and one
plate for the PTO drive.
The clutch housing has an air intake for more effective cooling of the clutch
components. The controls are completely separate: pedal for the main
clutch and hand lever for the PTO clutch.
Technical characteristics
Clutch plate - main clutch 35HP - 45HP - 55HP
clutch type plate with circular friction linings
control type mechanical, pedal operated
clutch plate diameter mm 225
in 8,86
clutch plate thickness mm 10
in 0,39
friction material organic
clutch pedal free travel mm 25
in 0,98
Clutch plate - PTO 35 HP - 45 HP - 55 HP
clutch plate diameter mm 225
in 8,86
clutch plate thickness mm 7.5
in 0,29
friction material RAYBESTOS asbestos free
clutch type: plate with circular friction linings
control type: mechanical, hand lever operated
Power take-off
Mid stub shaft (UNI 221) 6X21X25
Rear stub shaft 1 3/8" 6-spline SAEJ 1170
Can be synchronised with the engine with ratios:
4.9000 for 540 rpm rear
3.7333 for 750 rpm rear
2.7368 for 1000 rpm rear
1.5263 for 2000 rpm Central
182

SAME SOLARIS 55 Specifications

General

Power	55 hp
Transmission	Mechanical
PTO Power	48 hp
PTO Speed	540/1000 rpm
Gearbox	12
Hydraulic Remotes	2
Engine Type	Diesel
