SECTION V MAINTENANCE

Checking operation of the differential lock controls

Operate the controls and check that the differential lock is engaged and

disengaged correctly.

Hydrostatic steering

1 - Hydrostatic steering cylinder

2 - Cylinder oil drain fitting

3 - Front axle clearance adjustment screw

4 - Hinge pin front greaser

5 - Front towing hook

6 - Front axle oscillation angle adjustment screw

143

WARNING: FOR WHEELS DISASSEMBLING AND FOR MAINTE

NANCE AND REPAIR, LIFT THE TRACTOR, USING SPECIFIC TOOLS

ONLY.
