SECTION III USE
Class “A” drawbar
•
(optional)
Swinging drawbar of the type commonly used for towing agricultural
implements, for trailers with more than one axle and consequently with low
vertical load.
To facilitate trailer attachment, the drawbar consists of a swinging bar with
horizontal adjustment.
•
It is secured to the tractor under the gearbox with the aid of the
central hole on the end of the bar.
•
To adjust the horizontal position of the bar, withdraw the pin, move
the bar to the required position, and then replace the pin and se-
cure it with the lock pin
64
WARNING - NEVER ALLOW ANYONE TO RIDE ON THE DRAWBAR
OR THE LOWER LIFT ARMS WHEN THE TRACTOR IS IN MOTION.
