SECTION V MAINTENANCE
Four wheel drive tractor front drive axle
1 - Hub oil drain screw plug
2 - Steering angle adjusters.
Warning: Whenever you change the tyres or adjust the track, make sure that there
is no interference between the tyres and the engine hood with the front axle fully in-
clined and fully steered. If necessary, adjust the steering angle adjusters accord-
ingly.
146
CAUTION: ALL IMPLEMENTS MOUNTED TO THE TRACTOR MUST
BE SAFELY ATTACHED.
WARNING: THE IMPLEMENTS MUST ALWAYS BE LOWERED TO
THE GROUND WHENEVER THE TRACTOR IS NOT OPERATING OR
WHEN ADJUSTMENT, MAINTENANCE OR REPAIR OPERATIONS
ARE TO BE CARRIED OUT.
DANGER: BEFORE DOING ANY JOB ON THE P.T.O. DRIVE LINE AND
P.T.O. END SHAFT, ENSURE THAT PTO IS DISENGAGED, THE
ENGINE SHUT OFF AND THE KEY REMOVED.
