SECTION VI ELECTRICAL SYSTEM
To remove the battery from the tractor, proceed as follows:
1 – The battery is located in the front of the
engine compartment. The engine hood must
be lifted to access the battery.
Disconnect the earth lead from the negative
terminal first and then disconnect the lead
from the positive terminal.
2 – Loosen the 2 retaining screws from the
battery bracket and remove the battery from
the mounting tray.
Always keep the battery terminals clean;
smear them with vaseline to protect them agianst corrosion.
When refitting the battery, always connect the positive lead first and then
the earth lead.
Important: Check frequently that the battery is securely anchored to its
support.
Engine front compartment
158
DANGER: MAKE SURE YOU CONNECT THE BATTERY TERMINALS
CORRECTLY. DANGER OF SHORT-CIRCUIT!
