5.2.12. Air supply to the spray box
The spray box is used to supply or cut off the spray air that reaches the gun. The air consumption also allows the
machine to know if the gun is open or closed thanks to the debistats located in the box. This means that this box
must be fed from the outlet of the debistats on the box and then the air supply to the gun will be from this box.
M1/4 NPS (to the gun)
Ø2.7x4
Spray air control
Ø8x10
