6.1. Maintenance summary table
The frequency of maintenance indicated in the procedures below is only indicative.
The user will have to create his own maintenance range as he uses the Sames equipment.
Procedure Detail Duration Frequency
Maintenance of the concerned sub-assembly
screen filter - screen seals
Replacement
Remove the screen filter. 2mn30s 1000 hours
Reassemble the screen filter. 2mn30s
1000 hours
Remove the seals. 1mn
2000 hours
(Once a year)
Reassemble the seals. 1mn
2000 hours
(Once a year)
Maintenance of the concerned sub-assembly
regulator body - fluid air diaphragm
Remove the fluid air diaphragm. 5mn
2000 hours
(Once a year)
Reassemble the fluid air diaphragm.
5mn
2000 hours
(Once a year)
Maintenance of the concerned sub-assembly
regulator body - seat, spring and ball
Remove the seat, spring and ball. 2mn30s
2000 hours
(Once a year)
Reassemble the seat, spring and ball. 2mn30s
2000 hours
(Once a year)
Maintenance of the concerned sub-assembly
injection valve - cartridge replacement
Remove the injection valve. 5mn
2000 hours
(Once a year)
Reassemble the injection valve.
5mn
2000 hours
(Once a year)
Maintenance of the concerned sub-assembly
color changers - cartridge replacement
Remove the color changer - Cartridge replacement.
8mn30s
(Once a year)
Reassemble the color changer - Cartridge replacement. 8mn30s
(Once a year)
Maintenance of the concerned sub-assembly
color changers - needle and pneumatic valve replacement
Remove the color changer.
Needle and pneumatic valve replacement.
5mn (Once a year)
Remove the color changer.
Needle and pneumatic valve replacement.
5mn (Once a year)
Maintenance of the concerned sub-assembly mixer
Remove the mixer. 5mn (Once a year)
Reassemble the mixer. 5mn (Once a year)
Maintenance of the concerned sub-assembly flowmeter
Remove the flowmeter.
5mn 4000 hours
(Once every 2 years)
Reassemble the flowmeter.
5mn
4000 hours
(Once every 2 years)
