2.4. Principle of designation and codification
A Cyclomix
®
Evo is made up of a product board and a control box that allows all the elements on the product board
to be controlled.
These 2 elements constitute a set with a commercial reference and which is described by a significant designation.
The significant designation is a code that allows the Cyclomix
®
Evo to be defined, manufactured and configured in
its entirety. It can be built using the configurator provided by SAMES.
As well as the complete assembly, the product board and the cabinet are also defined by a meaningful designation.
Each meaningful designation is associated with a part number and a trade name.
2.4.1. Principle of significant designation of the Cyclomix
®
Evo
Codification of the board and box assembly
The meaningful designation is composed of 59 characters that allow the Cyclomix® Evo to be defined, manufactured
and configured in its entirety.
The meaningful designation of a Cyclomix® Evo is divided into 9 groups, each defining a part of the dosing unit.
These 9 groups are preceded by a prefix: #EVO-.
• The first group gives information about the technology, it allows to define the number of components, the
admissible product pressure and the type of platinum.
• The second, third and fourth groups allow to define the different components base, catalyst and diluent.
• The fifth group is for injection and mixing.
• The sixth group concerns the product regulation.
• The seventh group concerns the management of paint circuits.
• The eighth group concerns the options.
• The ninth and last group concerns the management box.
Example of a significant designation.
Technology block
The ''technology'' block is composed of 3 characters:
• The first character concerns the number of components managed by the Cyclomix
®
Evo.
• The second character concerns the type of platinum and the material of the components.
• The third character concerns the maximum allowable working pressure.
Prefix Technology Comp. A Comp. B Comp. C
Injection and
mixing
Product
regulation
Painted
circuits
Options
Control
panel
#EVO - 3XM - 04X131 - 02X131 - 02X161 - 3232H1H1 - A4 - 10001 - 21000RX - 12
Number of components Type of plate Working pressure
2 2 components (A + B) X Injection block in stainless steel 303 M Maximum pressure 240b
3 3 components (A+B+C) S Injection block in stainless steel 316
C Box only
P
PH compatible (Injection block, 303
stainless steel on base side and 316
stainless steel on catalyst side)
