Component blocks (Comp. A / Comp. B / Comp. C)
The ''component'' blocks are composed of 6 characters:
• The first 2 characters concern the number of products that can be connected to this component (products and
solvents included).
• The 3
rd
character indicates the presence or not of a filter on the component.
• The 4
th
character indicates the type of flow meter installed on the component.
• The 5
th
character indicates the size of the flowmeter installed on the component.
• The 6
th
character indicates the type of fitting installed on the shade changer.
Number of
products
Product filter Flowmeter type
Size and material of
flowmeter
Type of connections
on the color
changers
01 1 product X No filter 1
ATEX gear
flowmeter
1
0.07cc/teeth
Stainless steel
303
0
CTM Inox 303
without fitting
--
F Pencil filter
2
NON ATEX gear
flowmeter
2
0.12cc/teeth
303 stainless
steel
1
CTM Stain-
less Steel 303
1/2 JIC 303
fittings
99 99 products 3
Débitmètre
engrenage
ATEX 0.07cc
3
0.24cc/teeth
303 stainless
steel
2
CTM Inox 303
fittings 3/8
NPSM 303
4
NON ATEX gear
flowmeter
0.07cc
4
0.07cc/teeth
Stainless steel
316
3
CTM Stain-
less steel 316
1/2 JIC 316
fittings
5
Fiber optic
flowmeter
5
0.12cc/teeth
Stainless steel
316
4
CTM
Stainless
Steel 316 3/8
NPSM 316
fittings
6
0.07cc fiber
optic flowmeter
6
0.24cc/teeth
Stainless steel
316
5
CTM Stain-
less steel 316
without
fittings
7
ATEX mass
flowmeter
7
Rheonik
RHM-03
8
NON ATEX
mass flowmeter
8
Rheonik
RHM-04
