Injection and mixing block
The block ''injection and mixture'' is composed of 8 characters:
• The first character indicates the size of the product B injector.
• The second character indicates the type of injection valve for product B.
• The third character indicates the size of the product injector C.
• The fourth character indicates the type of injection valve for product C.
• The fifth character indicates the type of mixer for mixture A+B.
• The sixth character indicates the number of mixers for mixture A+B.
• The seventh character indicates the type of mixer for mixture A+B+C.
• The eighth character indicates the number of mixers for the mixture A+B+C.
Product control block
The regulation block is composed of 2 characters.
• The first character corresponds to the type of controller produced.
• The second character indicates the presence or absence of a pressure gauge and the measuring pressure.
Injector size B
Injection valve
type B
Injector size C
Injection valve
type C
Type of mixer
A+B
Injection and
mixing
Mixer type
A+B+C
Number of
mixer A+B+C
0 None 0 None 0 None 0 None 0 None 1 1 mixer 0 None 1 1 mixer
1 Not used 1
Carbide ball
point /
PTFE gasket
cartridge
1 Not used 1
Carbide
ball point
/ PTFE
gasket
cartridge
1 Flexible 2 2 mixers 1 Flexible 2 2 mixers
2 Not used 2
Carbide ball
point /
PTFE gasket
cartridge
2
Injector
size 45
2
Carbide
ball point
/ GT joint
cartridge
3 3 mixers 3 3 mixers
3
Injector
size 100
3
Carbide ball
point /
PTFE gasket
cartridge
3
Injector
size 100
3
peek /
peek pin
PTFE
gasket
cartridge
4
Injector
size 200
4
Carbide ball
point /
PTFE gasket
cartridge
4
Injector
size 200
4
peek /
peek pin
PTFE
gasket
cartridge
5
Carbide ball
point /
PTFE gasket
cartridge
5
Peek /
peek pin
cartridge
seal PTFE
Stainless
steel 316
Type of regulator Pressure gauge
0 None 0 None
2 40-6B piloted regulator 1 0-16B pressure gauge
4 5-40B piloted regulator 2 0-40B pressure gauge
6 5-70B piloted regulator 3 0-160B pressure gauge
8 10-160B piloted regulator 4 0-250B pressure gauge
A 10-200B piloted regulator
