Painting circuit block
The paint circuit block allows you to define the characteristics of the circuit(s) downstream of the Cyclomix
®
Evo.
• The first character is used to define the number of circuits (gun).
• The second character is used to define the number and type of fast purge valve.
• The 3
rd
and 4
th
characters are reserves.
• The 5
th
character is used to define the number of atomization air boxes included in the Cyclomix
®
Evo.
Options block
The ''Options'' block contains various information on the configuration of the Cyclomix® Evo.
• The first character is used to define the length of the pneumatic cables and hoses required between the
product board and the control unit.
• The second character is used to define the type of connections installed on the 2-gun management block.
• The third character is used to indicate the presence or absence of pressure sensors.
• The fourth character is used to indicate the presence or absence of temperature sensors.
• The fifth character is reserved for a future function.
• The sixth character indicates the type of management concerning the controllers produced (if present).
• The seventh character is used to specify whether the product board is mounted on a frame.
Number of circuit(s) Number of dump valves Reserve Reserve Atomization air casing
1 1 gun 0 None 0 - 0 - 0 None
2 2-gun management 1 1 dump valve 1 1 casing
3
Management of 2
guns with flushing
2 2 dump valves 2 2 casings
3 1 dump valve with flushing
4 1 dump valve with flushing
Length of
the cables
2-gun
block fittings
Pressure sensor
Temperature
sensor
Waste sorting
(function to be
developed)
Management of
product regulators
Frame for
product board
1 5 meters 0 None 0 None 0 None 0 No 0 None 0 None
2 10 meters 1 1/2 JIC 303 1
Pressure sensor
0-16B
1
1
temperature
sensor
1
Block
2 outputs
with EV
1
Manual control
board
1
Product plate on
frame
3 15 meters 2 3/8 NPSM 303 2
Capteur de
pression 0-250B
2
2
temperature
sensors
2
Block
4 outputs
with EV
2
Management by
proportional valves
4 20 meters 3 1/2 JIC 316 3
Block
6 outputs
with EV
4 3/8 NPSM 316 4
EV only
without
output block
5
