If the machine is equipped with a 2-gun module, then following the
selection of the recipe it will be necessary to select the gun or guns
that will be used.
If both guns are selected then the priming will be done on both circuits
starting with circuit 1 and if not the priming will be done only on the
selected circuit.
Following the selection of the recipe in the case of a configuration with
only one gun or following the selection of the gun(s) in the case of a
configuration with two guns, the Cyclomix
®
Evo automatically
switches to the priming phase
The priming screen displays a certain amount of information that allows you to follow the evolution of this phase.
Once the priming is completed, the Cyclomix
®
Evo goes directly to the production phase
Reference points Designation
1 Indicates the name of the current recipe
2
Bar graph indicating the evolution of the priming
3 Indicates the ratio requested in the recipe with the actual ratio next to it
4 Indicates the evolution of the volume starting from 0
5 Indicates temperature and pressure information
6 Indicates the gun or guns used
7 Button to go directly to production without priming
8
Button to stop the priming and return to the main screen. The machine is considered
to be in paint and a flushing cycle will be carried out following the call for a new
recipe.
