From the PLC to the Cyclomix
®
Evo module
2 words are exchanged from PLC to the Cyclomix
®
Evo.
**Recipe number: when editing recipe, check your recipe number as it can change when adding or deleting
recipes.
From the Cyclomix
®
Evo module to the PLC
Label Parameter description
0 PLC_Command_1 Commands requested by the PLC (see description hereafter)
1 PLC_Command_2 Commands requested by the PLC (see description hereafter)
PLC_Command_1 Détail de la commande PLC mot 0 en bit
15
12
13
11
10
9
8
7
6
5
Push color gun 2 Set the bit to "1" to start paint optimisation on gun 2 (hold).
4
Push color gun 1 Set the bit to "1" to start paint optimisation on gun 1 (hold).
3
Gun 2 open Set the bit to "1" to indicate that gun 1 is open (hold).
2
Gun 1 open Set the bit to "1" to indicate that gun 1 is open (hold)..
1
Gun 2 in use Set the bit to "1" to use the gun in production.
0
Gun 1 in use Set the bit to "1" to use the gun in production.
PLC_Command_2 Detail of PLC command word 1 in bit
15
Reset consumption Set the bit to "1" to clear the consumption of the active recipe.
14
Reset alarm Set the bit to "1" to clear the active errors.
13
12
11
Machine flush Set the bit to "1" to do a machine flush (hold).
10
9
8
Production flush Set the bit to "1" to do a production flush (hold).
7
Start production Set the bit to "1" to start a production (hold).
6
Change colour Set the bit to "1" to start a change of colour (hold).
5
Recipe number Number of the recipe * (recipe index) to launch in production.
4
3
2
1
0
