Samson 3374 Series User Manual

EB 8331-4 EN 5-7
Installation
1 23
4
8
12
13
17 21
11
18
1 Intermediate gear
2 Spindle gear
3 Serrated ring
4 Tension spring
8 Spacer
11 Spindle
12 Actuator board
13 Bearingsleeve
17 Terminal board
18 Adjustment gear
21 Contact cam unit
State on delivery:
Spindle (11) with
serrated ring and shim
Fig.5-10: Installing the limit contacts
