Samson 3374 Series User Manual

EB 8331-4 EN 7-7
Start-up and conguration
Displayed reading: state
Fig.7-3: Start screen with two-step mode application (2STP)
Three-step mode application (see AnnexA for description)
Î Set Code 6 to 3STP.
Î Perform the connection as described in the 'Installation' section.
Displayed reading: state
Fig.7-4: Start screen with three-step mode application (3STP)
Temperature closed-loop control upon input signal failure application (see AnnexA for de-
scription)
Î Set Code 6 to POSF.
Î Perform the connection as described in the 'Installation' section.
%
Displayed reading: travel
Fig.7-5: Start screen with temperature closed-loop control upon input signal failure application
(POSF)
The 0 to 10V or 0 to 20mA setting for the input signal is not possible in combination with
this function. The lower value must be at least 0.5V or 1mA.
Note
