Communication
Phone number of control station
Enter the phone number of the control system modem including the dialing code, if neces-
sary. Short pauses between the numbers can be entered using P (= 1 second); the end of the
string is to be marked by '–'. The phone number may include a maximum of 22 characters.
Example: 069, 2 sec. pause, 4009, 1 sec. pause, 0:
0 6 9 P P 4 0 0 9 P 0 – (= 11 characters)
Note:
The connected modem is automatically congured when the function block CO6 >
F04 - 1 is activated.
10.4 Meter bus
TROVIS5573-100x version
The controller can be connected to an optional meter bus/Modbus gateway (1400-9867)
(RJ-45 connector socket). The gateway can communicate with up to six M-Bus units accord-
ing to EN1434-3. Flow rate and/or capacity limitations in RK1 or RK2 control circuit is pos-
sible on the basis of the values measured at heat meter WMZ1 and WMZ2.
TROVIS5573-110x version
The controller has an interface for three M-bus units according to EN1434-3. Flow rate
and/or capacity limitations in RK1 or RK2 control circuit is possible on the basis of the values
measured at heat meter WMZ1 and WMZ2.
Note:
Details on the use of the different heat or water meters can be found in the technical
documentation TV-SK6311.
10.4.1 Activating the meter bus
To successfully transfer data from the heat meter, the heat meter must use a standardized pro-
tocol in accordance with EN1434-3. It is not possible to make a general statement about
which specic data can be accessed in each meter. For details on the different meter makes,
refer to the technical documentation TV-SK 6311. All necessary function block parameters to
set up the communication with heat meters are available in CO6 > F10. The meter bus ad-
dress, model code and reading mode must be specied for the heat meters WMZ1 to WMZ6
(TROVIS5573-100x) or WMZ1 to WMZ3 (TROVIS5573-110x). A meter bus address must


