Samson TROVIS 5500 - 13 Appendix; Function Block Lists

132 EB 5573-1 EN
Appendix
13 Appendix
13.1 Function block lists
CO1: RK1 · Heating circuit 1 (not system Anl1.9)*
F Function WE System
Comments
Function block parameters: value range (default setting)
01 Room sensor 0
Not Anl
1.5, 1.6,
3.x
CO1 > F01 - 1: Room sensor RF1, temperature reading and
FG1 input for Type5257-5 Room Panel active
02 Outdoor sensor 0
1.5, 1.6
CO1 > F02 - 1: Outdoor sensor AF1, weather-compensated
control active
1
Not Anl
1.5, 1.6
03 Return ow
sensor
0
1.2
CO1 > F03 - 1: R eturn ow sensor RüF1, limitation function ac-
tive
Function block parameters:
KP (limiting factor): 0.1 to 10.0 (1.0)
1
Not Anl
1.2
04 Cooling control 0
All*
CO1 > F04 - 1: Cooling control, only with CO1 > F11 - 1
The cooling control function causes a reversal of the operating
direction and a minimum limitation of the return ow tempera-
ture in RK1.
05 Underoor
heating
0
Not Anl
1.5, 1.6,
3.x
CO1 > F05 - 1: Underoor heating/drying of jointless oors
Function block parameters:
Start temperature: 20.0 to 60.0°C (25°C)
Temp. rise/day: 0.0 to 10.0 °C (5.0°C)
Maximum temperature: 25.0 to 60.0°C (45.0°C)
Duration: 0 to 10 days (4 days)
Temp. reduction/day: 0.0 to 10.0°C (0.0°C)
Start condition: Stop, Start, Hold, Reduction
07 Optimization 0
Not Anl
1.5, 1.6,
3.x
CO1 > F07 - 1: Optimization of heating times
(only with CO1 > F01 - 1 and CO1 > F02 - 1)
08 Adaptation 0
Not Anl
1.5, 1.6,
3.x
CO1 > F08 - 1: Heating characteristic adaptation
(only with CO1 > F01 - 1, CO1 > F02 - 1 and CO1 > F11 - 0)
09 Flash
adaptation
0
Not Anl
1.5, 1.6,
3.x
CO1 > F09 - 1: Flash adaptation of ow temperature
(only with CO1 > F01 - 1)
Function block parameters:
Cycle time: 0 or 1 to 100min (20min)
KP (gain): 0.0 to 25.0 (0.0)
