Samson TROVIS 5500 - Domestic Hot Water Heating with Solar System

EB 5573-1 EN 93
Functions of the DHW circuit
Functions WE Conguration
Flow rate sensor 0
Analog
CO4>F04 - 1
Selection: Analog (ow rate sensor), binary
(ow switch)
Parameters WE Switch position: value range
Day set point for DHW temperature 55.0°C
: Min. to max. adjustable DHW set point
Night set point for DHW temperature 40.0°C
: Min. to max. adjustable DHW set point
Parameters WE Parameters: value range
Min. adjustable DHW set point 40.0°C PA4 > P01: 5.0 to 90.0°C
Max. adjustable DHW set point 60.0°C PA4 > P02: 5.0 to 90.0°C
7.4 Domestic hot water heating with solar system
The systems Anl 1.3 and 2.3 are tted with a solar system for DHW heating. In these sys-
tems, the difference between the temperatures measured at storage sensor SF2 and the sen-
sor at the solar collector VF3 is determined. The 'Solar circuit pump ON' parameter deter-
mines the minimum temperature difference between sensors VF3 and SF2 required to acti-
vate the solar circuit pump. If the temperature difference falls below the value of 'Solar circuit
pump OFF', the solar circuit pump is switched off. If the temperature difference falls below
the value of 'Solar circuit pump OFF', the solar circuit pump is switched off. Basically, the so-
lar circuit pump is also switched off when the water temperature measured at sensor SF2 has
reached the 'Max. storage tank temperature'.
Note:
The times-of-use of the DHW circuit do not affect the operation of the solar system.
After the key number 1999 has been entered, the operating hours of the solar circuit pump
are displayed in the extended operating level. See page9.
Parameters WE Parameters: value range
Solar circuit pump ON 10.0°C PA4 > P10: 1.0 to 30.0°C
Solar circuit pump OFF 3.0°C PA4 > P11: 0.0 to 30.0°C
Max. storage tank temperature 80.0°C PA4 > P12: 20.0 to 90.0°C

