Samson TROVIS 5500 - Resistance Values

150 EB 5573-1 EN
Appendix
13.3 Resistance values
Temp.°C –35 –30 –25 –20 –15 –10 –5 0 5 10 15 20
Resistance Ω 862.5 882.2 901.9 921.6 941.2 960.9 980.4 1000.0 1019.5 1039.0 1058.5 1077.9
Temp.°C 25 30 35 40 45 50 55 60 65 70 75 80
Resistance Ω 1097.3 1116.7 1136.1 1155.4 1174.7 1194.0 1213.2 1232.4 1251.6 1270.8 1289.9 1309.0
Temp.°C 85 90 95 100 105 110 115 120 125 130 135 140
Resistance Ω 1328.1 1347.1 1366.1 1385.1 1404.0 1422.9 1441.8 1460.7 1479.5 1498.3 1517.1 1535.8
Temp.°C 145 150 155 160 165 170 175 180 185 190 195 200
Resistance Ω 1554.6 1573.3 1591.9 1610.5 1629.1 1647.7 1666.3 1684.8 1703.3 1721.7 1740.2 1758.6
