Communication
Functions WE Conguration
Flow rate limitation in RK1 0
1.5m³/h
1.5m³/h
1.5m³/h
1.0
CO6 > F11 - 1
Max. limit: At, 0.01 to 650m³/h
Max. limit for heating: At, 0.00 to 650m³/h
Max. limit for DHW: 0.01 to 650m³/h
Limiting factor: 0.1 to 10.0
Flow rate limitation in RK2 0
1.5
1.0
CO6 > F13 - 1
Max. limit: 0.01 to 650
Limiting factor: 0.1 to 10.0
* TROVIS5573-100x: WMZ1...6; TROVIS5573-110x: WMZ1...3
Capacity limitation
All necessary function block parameters to set up the capacity limitation are available in
CO6 > F12 or CO6 > F14 for systems with two control valves. One after the other, the sys-
tem's max. limit or max. limit for heating and the max. limit for DHW for systems with only
one control valve and secondary DHW heating have to be set. The 'Limiting factor' deter-
mines how strongly the controller responds when the limit values are exceeded in either di-
rection.
NOTICE
If the controller indicates CO5>F00 - 1, any access to the return ow, ow rate and
capacity settings is locked.
Functions WE Conguration
Meter bus 0
255
1434
24h
CO6 > F10 - 1
WMZ1...x address*: 0 to 255
WMZ1...x model code*: 1434, CAL3, APAtO, SLS
WMZ1...x reading mode*: 24h, CONT, CoiL
Capacity limitation in RK1 0
1.5kW
1.5kW
1.5kW
1.0
CO6 > F12 - 1
Max. limit: At, 0.1 to 6500kW
Max. limit for heating: At, 0.0 to 6500kW
Max. limit for DHW: 0.1 to 6500kW
Limiting factor: 0.1 to 10.0
Capacity limitation in RK2 0
1.5kW
1.0
CO6 > F14 - 1
Max. limit: 0.01 to 6500kW
Limiting factor: 0.1 to 10.0
* TROVIS5573-100x: WMZ1...6; TROVIS5573-110x: WMZ1...3
