EB 5573-1 EN 153
Appendix
PA1 parameters (heating circuit HC1) and PA2 parameters (heating circuit HC2)
P Parameters PA1 (HC1) PA2 (HC2) Value range
01 Flow gradient 0.2 to 3.2
02 Level (parallel shift) –30.0 to 30.0°C
03 Flow set point (day) –5.0 to 150.0°C
04 Flow set point (night) –5.0 to 150.0°C
05 Four-point characteristic
Outdoor temperature, point 1 –30.0 to 50.0°C
Outdoor temperature, point 2 –30.0 to 50.0°C
Outdoor temperature, point 3 –30.0 to 50.0°C
Outdoor temperature, point 4 –30.0 to 50.0°C
Flow temperature, point 1 –5.0 to 150.0°C
Flow temperature, point 2 –5.0 to 150.0°C
Flow temperature, point 3 –5.0 to 150.0°C
Flow temperature, point 4 –5.0 to 150.0°C
Reduced ow temperature, point 1 –5.0 to 150.0°C
Reduced ow temperature, point 2 –5.0 to 150.0°C
Reduced ow temperature, point 3 –5.0 to 150.0°C
Reduced ow temperature, point 4 –5.0 to 150.0°C
Return ow temperature, point 1 5.0 to 90.0°C
Return ow temperature, point 2 5.0 to 90.0°C
Return ow temperature, point 3 5.0 to 90.0°C
Return ow temperature, point 4 5.0 to 90.0°C
Flow rate, point 1 – 0.00 to 650m³/h
Flow rate, point 2 – 0.00 to 650m³/h
Flow rate, point 3 – 0.00 to 650m³/h
Flow rate, point 4 – 0.00 to 650m³/h
Capacity, point 1 – 0.0 to 6500kW
Capacity, point 2 – 0.0 to 6500kW
Capacity, point 3 – 0.0 to 6500kW
Capacity, point 4 – 0.0 to 6500kW
06 Min. ow temperature –5.0 to 150.0°C
