Samson TROVIS 5500 - Page 156

156 EB 5573-1 EN
Appendix
F Function block parameters CO4 (DHW) Value range
05 Stop 0 to 10min
05 Temperature limit 20.0 to 90.0°C
08 Start 0 to 10min
08 KP (inuence factor) 0.1 to 10.0
08 Control circuit (only system Anl 4.5) HC1, HC2, HC1+HC2
09 Start 0 to 10min
09 Control circuit (only system Anl 4.5) HC1, HC2, HC1+HC2
12 KP (gain) 0.1 to 50.0
12 Tn (reset time) 1 to 999s
12 TV (derivative-action time) 0 to 999s
12 TY (valve transit time) 5 to 240s
12 Hysteresis 1.0 to 30.0°C
12 Min. ON time 0 to 10min
12 Min. OFF time 0 to 10min
13 Max. system deviation 2.0 to 10.0°C
14 Day of the week 1 to 7
14 Time Adjustable as required
14 Boost 60.0 to 90.0°C
14 Duration 0 to 255min
14 Active when BI = ON, OFF
21 Start speed reduction 5.0 to 90.0°C
21 Stop speed reduction 5.0 to 90.0°C
21 Min. speed signal 0 to 10V
CO5 function block parameters (system-wide functions)
F Function block parameters CO5 Value range
04 Time Adjustable as required
04 No. days until activation 1 to 3
04 No. days until deactivation 1 to 3
04 Limit 0.0 to 30.0°C
05 Delay/h 1.0 to 6.0°C
