158 EB 5573-1 EN
Appendix
F Function block parameters CO6 Value range
10 WMZ4 address
(TROVIS5573-100x only) 0 to 255
10 WMZ4 model code
(TROVIS5573-100x only) 1434, CAL3, APAtO, SLS
10 WMZ4 reading mode
(TROVIS5573-100x
only)
24h, CONT, CoiL
10 WMZ5 address
(TROVIS5573-100x only) 0 to 255
10 WMZ5 model code
(TROVIS5573-100x only) 1434, CAL3, APAtO, SLS
10 WMZ5 reading mode
(TROVIS5573-100x
only)
24h, CONT, CoiL
10 WMZ6 address
(TROVIS5573-100x only) 0 to 255
10 WMZ6 model code
(TROVIS5573-100x only) 1434, CAL3, APAtO, SLS
10 WMZ6 reading mode
(TROVIS5573-100x
only)
24h, CONT, CoiL
11 Max. limit At, 0.01 to 650m³/h
11 Max. limit for heating At, 0.00 to 650m³/h
11 Max. limit for DHW 0.01 to 650m³/h
11 Limiting factor 0.1 to 10
12 Max. limit At, 0.1 to 6500kW
12 Max. limit for heating At, 0.0 to 6500kW
12 Max. limit for DHW 0.1 to 6500kW
12 Limiting factor 0.1 to 10
13 Max. limit 0.01 to 650m³/h
13 Limiting factor 0.1 to 10
14 Max. limit 0.1 to 6500kW
14 Limiting factor 0.1 to 10
CO8 function block parameters (initialization of BI1 and BI2)
F Function block parameters CO8 Value range
1 Error message when BI = 0, BI = 1, none (1)
2 Limiting factor BI = 0, BI = 1, none (1)
