EB 5573-1 EN 63
Systems
System Anl 11.6
BE
BA
AE
RK
WW
KW
RK2
Z
RK1/Y1 RüF1
VF2VF1 SF2 UP1 AF1
RüF2 SLP/ZP SF1 RF1
*
* Note:
Install a continuously running pump in the DHW circuit and con-
nect it directly to the main power supply.
Default settings
CO1 > F01 - 0 (without RF1)
CO1 > F02 - 1 (with AF1)
CO1 > F03 - 1 (with RüF1)
CO4 > F01 - 1 (with SF1)
CO4 > F02 - 1 (with SF2)
CO4 > F03 - 0 (without RüF2)
