10.7.6 Open Loop1 (Addtional)
LED
display
Parameter
Min/Max
range
Description
Factory
defaults
Adj.
During
run
I17
Multi-function
input
terminal P1 define
0 ~ 29
0
Forward run command (FX)
0 O
1
Reverse run command (RX)
I18
Multi-function
input
terminal P2 define
2
Emergency Stop Trip
1 O
3
Reset when a fault occurs
I19
Multi-function
input
terminal P3 define
4
Jog operation command
2 O
5
Multi-step freq- Low
I20
Multi-function
input
terminal P4 define
6
Multi-step freq- Middle
3 O
7
Multi-step freq- High
I21
Multi-function
input
terminal P5 define
8
Multi Accel/Decel-Low
4 O
9 Multi Accel/Decel-Middle
I22
Multi-function
input
terminal P6 define
10
Multi Accel/Decel-High
5 O
11
DC brake during hold
I23
Multi-function
input
terminal P7 define
12
2nd motor select
6 O
13
-Reserved-
I24
Multi-function
input
terminal P8 define
14
-Reserved-
7
O
15
Up-
down
Frequency
increase command
16
Frequency
decrease
command
17
3-wire operation
18
External trip: A contact (EtA)
19
External trip: B contact (EtB)
20
Self-diagnostic function
21 Change PID operation to
normal operation
22
2nd source select
23
Analog hold
24
Accel/Decel hold
25
Up/Down Save
Freq.Initialization
26
JOG-FX
27
JOG-RX
28
Open Loop1
29
Fire Mode
