11.5 Multi-function output terminal (MO) and Relay (3AC)
Group Code Parameter Setting range Initial
I/O
group
I54
[Multi-function
output terminal
select]
0
FDT-1 12
1
FDT-2
I55
[Multi-function
relay select]
2
FDT-3 17
3
FDT-4
4
FDT-5
5
Overload {OLt}
6
Inverter Overload {IOLt}
7
Motor stall {STALL}
8
Over voltage trip {OV}
9
Low voltage trip {LV}
10
Inverter overheat {OH}
11
Command loss
12
During run
13
During stop
14
During constant run
15
During speed searching
16
Wait time for run signal input
17
Fault output
18
Cooling fan trip alarm
I56
[Fault relay
output]
When
setting the
H26–
[Number
of auto
restart]
When a
trip,
different
than low
voltage
occurs
When low
voltage
trip occurs
Bit 2 Bit 1 Bit 0
0
- - - 2
1
- -

2
-

-
3
-
 
4 
- -
5 
-

6  
-
7   

Select the desired item to be output via MO terminal and relay (3AC).
