CHAPTER 15 - SPECIFICATIONS
 Input & output ratings: 200-230V
SINUS M ■ ■ ■ 2S/T
BA2K2
0001 0002 0003 0005 0007 0011 0014 0017 0020 0025 0030
Max capacity
1
Motor power
200-230Vac
[HP] 0.5 1-1.5 2-2.5 3-4 5.5-6 7.5
10-
12.5
15 20 25 30
[kW] 0.4
0.75-
1.1
1.5-
1.8
2.2-3
4.0-
4.5
5.5
7.5-
9.2
11 15 18.5 22
Output
ratings
Capacity
[kVA]
2
0.95 1.9 3.0 4.5 6.5 9.1 12.2 17.5 22.9 28.2 33.5
FLA [A]
3
2.5 5 8 12 17 24 32 46 60 74 88
Max
Frequency
400 [Hz]
4
Max
Voltage
3Φ 200 ~ 230V
5
Input
ratings
Rated
Voltage
3Φ 200 ~ 230 VAC (+10%, –15%)
Rated
Frequency
50 ~ 60 [Hz] (±5%)
Cooling method N/C
6
Forced cooling
Weight [kg] 0.76 0.77 1.12 1.84 1.89 3.66 3.66 9.0 9.0 13.3 13.3
 Input & output ratings: 380-480V
SINUS M ■ ■ ■ 4T
BA2K2
0001 0002 0003 0005 0007 0011 0014 0017 0020 0025 0030
Max capacity
1
Motor power
380-415Vac
[HP] 0.5
1-
1.25
2 3 5.5-6 7.5 10 15 20 25 30
[kW] 0.4
0.75-
0.9
1.5 2.2 4-4.5 5.5 7.5 11 15 18.5 22
Max capacity
1
Motor power
440-460Vac
[HP] 0.5
1-1.
5
2-3 3-4 5.5-6 7.5
10-
12.5
15 20 30 30
[kW] 0.4
0.75-
1.1
1.5-
1.8
2.2-3 4-4.5 5.5
7.5-
9.2
11 15 22 22
Output
ratings
Capacity [kVA]
2
0.95 1.9 3.0 4.5 6.9 9.1 12.2 18.3 22.9 29.7 34.3
FLA [A]
3
1.25 2.5 4 6 9 12 16 24 30 39 45
Max Frequency 400 [Hz]
4
Max Voltage 3Φ 380 ~ 480V
5
Input
ratings
Rated Voltage 3Φ 380 ~ 480 VAC (+10%, –15%)
Rated
Frequency
50 ~ 60 [Hz] (±5%)
Cooling method N/C
6
Forced cooling
Weight [kg] 0.76 0.77 1.12 1.84 1.89 3.66 3.66 9.0 9.0 13.3 13.3
1) Indicates the maximum applicable motor capacity when using a 4-pole ES Standard motor.
2) Rated capacity is based on 220V for 2S/T class and on 440V for 4T class.
3) Refer to section Inverter Efficiency and Heating Loss when Carrier frequency setting (H39) is
above 3kHz.
