7.4 I/O group 2
LED
display
Parameter name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
I0
[Jump code]
0 ~ 81
Sets the code number to jump.
1
O
I1
[Filter time
constant for NV
input]
0 ~ 9999
Adjusts the responsiveness of NV input
(–10V~0V).
10
O
I2
[NV input Min
voltage]
0 ~ –10
[V]
Sets the minimum negative input
voltage of V1 (–10V~0V) input.
0.00
O
I3
[Frequency
corresponding to
I2]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum negative voltage
of I2.
0.00
O
I4
[NV input Max
voltage]
0 ~ –10
[V]
Sets the maximum negative input
voltage of the V1 input (–10V~0V).
10.0
O
I5
[Frequency
corresponding to
I4]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum negative
voltage of I4.
50.00
O
I6
[Filter time
constant for V1
input]
0 ~ 9999
Adjusts the responsiveness of V1 input
(0 ~ +10V).
10
O
I7
[V1 input Min
voltage]
0 ~ 10
[V]
Sets the minimum positive voltage of
the V1 input.
0
O
I8
[Frequency
corresponding to
I7]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum positive voltage
of I7.
0.00
O
I9
[V1 input Max
voltage]
0 ~ 10
[V]
Sets the maximum positive voltage of
the V1 input.
10
O
I10
[Frequency
corresponding to
I9]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum positive voltage
of I9.
50.00
O
I11
[Filter time
constant for I
input]
0 ~ 9999
Sets the input section’s internal filter
constant for I input.
10
O
I12
[I input Min
current]
0 ~ 20
[mA]
Sets the minimum current of I input.
4.00
O
I13
[Frequency
corresponding to
I12]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum current of I
input.
0.00
O
I14
[I input Max
current]
0 ~ 20
[mA]
Sets the Maximum current of I input.
20.00
O
I15
[Frequency
corresponding to
I14]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum current of I
input.
50.00
O
I16
[Criteria for
Analog Input
Signal loss]
0 ~ 2
0: Disabled
1: activated below half of set value.
2: activated below set value.
0
O
