Santerno Sinus M - 7.4 I;O group 2

7-19
LED
display
Parameter
name
Min/Max
range
Description Factory defaults
Adj.
during
run
LED
display
I17
[Multi-function
input terminal
P1 define]
0 ~ 29
0
Forward run command
0
O
1
Reverse run command
I18
[Multi-function
input terminal
P2 define]
2
Emergency Stop (Est)
1
O
3
Reset when a fault occurs {RST}
I19
[Multi-function
input terminal
P3 define]
4
Jog operation command
2
O
5
Multi-Step freq – Low
I20
[Multi-function
input terminal
P4 define]
6
Multi-Step freq – Mid
3
O
7
Multi-Step freq – High
I21
[Multi-function
input terminal
P5 define]
8
Multi Accel/Decel – Low
4
O
9
Multi Accel/Decel – Mid
I22
[Multi-function
input terminal
P6 define]
10
Multi Accel/Decel – High
5
O
11
DC brake during hold
I23
[Multi-function
input terminal
P7 define]
12
2nd motor select
6
O
13
-Reserved-
I24
[Multi-function
input terminal
P8 define]
14
-Reserved-
7 O
15
Up-
down
Frequency increase
(UP)
command
16
Frequency decrease
command (DOWN)
17
3-wire operation
18
External trip: A Contact (EtA)
19
External trip: B Contact (EtB)
20
Self-diagnostic function
21
Change from PID operation
to normal operation
22
2nd source select
23
Analog Hold
24
Accel/Decel hold
25
Up/Down Save Freq.
Initialization
26
JOG-FX
27
JOG-RX
28
Open Loop1
29
Fire Mode
* See “Chapter 14 Troubleshooting and maintenance” for External trip A/B contact.
* Each multi-function input terminal must be set differently.
