Santerno Sinus M - 13.7 Parameter code list <Common area>

13-8
13.7 Parameter code list <Common area>
<Common area>: Accessible area regardless of inverter models (Note 1)
Address
Parameter
Scale
Unit
R/W
Data value
0x0000 Inverter capacity R
FFFF: 0.4kW
0000: 0.75kW
0001: n.u.
0002: 1.5kW
0003: 2.2kW
0004: 3.7kW
0005: 4.0kW
0006: 5.5kW
0007: 7.5kW
0008: 11.0kW
0009: 15.0kW
000A: 18.0kW
000B: 22.0kW
0x0001 Inverter Input Voltage R
0: 2S/T class
1: 4T class
0x0002
S/W Version
R
0x0023: Version EU2.3 (Note 2)
0x0003 Parameter Lock R
0: Lock (default)
1: Unlock
0x0004
Frequency Reference
0.01
Hz
R
Starting freq. ~ Max. freq.
0x0005 Run Command
R/W
BIT 0: Stop (0
→
1)
BIT 1: Forward run (0
→
1)
BIT 2: Reverse run (0
→
1)
W
BIT 3: Fault reset (0
→
1)
BIT 4: Emergency stop (0
→
1)
-
BIT 5, BIT 15: Not used
R
BIT 6~7: Output freq. arrival
0 (Terminal), 1 (keypad)
2 (Reserved), 3 (communication)
BIT 8~12: Freq. command
0: DRV–00, 1: Not used,
2~8: Multi-Step frequency 1~7
9: Up, 10: Down, 11: UDZero, 12: V0, 13: V1,
14: I, 15: V0+I, 16: V1+I, 17: Jog, 18: PID,
19: Communication, 20 ~ 31: Reserved
0x0006
Acceleration Time
0.1
sec
R/W
See Function List.
0x0007
Deceleration Time
0.1
sec
R/W
0x0008
Output Current
0.1
A
R
0x0009 Output Frequency 0.01 Hz R
0x000A Output Voltage 0.1 V R
0x000B
DC Link voltage
0.1
V
R
0x000C Output power 0.1 kW R
