Santerno Sinus M - 12.2 Overload Warning and trip; Overload trip; 12.3 Stall prevention

12-3
 Overload trip
Group Code Parameter Set Range Initial Unit
Function
group 1
F56 [Overload trip select] 1
0 ~ 1 1
F57 [Overload trip level] - 30 ~ 200 180 %
F58 [Overload trip time] - 0 ~ 60 60 sec

Set F56 to 1.
 Inverter output is turned off when motor is overloaded.
 Inverter output is turned off when excessive current flows to the motor for F58 – [Overload trip
time].
12.3 Stall prevention
Group Code Parameter Set Range Initial Unit
Function
group 1
F59 [Stall prevention select] -
0 ~ 7 0
F60 [Stall prevention level] -
30 ~ 200 150 %
I/O group
I54
[Multi-function output terminal
select]
7
0 ~18
12
I55 [Multi-function relay select] 7 17

During acceleration: Motor acceleration ramp is stopped when current exceeds the value set in
F60.
 During constant run: Motor decelerates when current exceeds the value set in F60.
 During deceleration: Motor deceleration ramp is stopped when inverter DC link voltage rises
above a certain voltage level.
 F60: The value is set as the percent of motor rated current (H33).
 I54, I55: Inverter outputs signals through multi-function output terminal (MO) or relay output
(3ABC) or external sequence when stall prevention function is activated. Motor stall status can be
monitored setting F59 different from (000).
 F59: Stall prevention can be set as the table below.
F59
Stall prevention
Setting
During
Deceleration
During
constant
speed
During
Acceleration
Bit 2
Bit 1
Bit 0
0 - - -
1 - -

2 -

-
3 -
 
4

- -
5

-

6
 
-
7
  
