Santerno Sinus M - 7.3 Function group 2

7-10
7.3 Function group 2
LED
display
Parameter name
Min/Max
range
Description
Factory
defaults
Adj.
during run
H0
[Jump code]
0~95
Sets the code number to jump.
1
O
H1
[Fault history 1]
-
Stores information on the types
of faults, the frequency, the
current and the Accel/Decel
condition at the time of fault.
The latest fault is automatically
stored in the H1- [Fault history
1].
nOn
-
H2
[Fault history 2]
-
nOn
-
H3
[Fault history 3]
-
nOn
-
H4
[Fault history 4]
-
nOn
-
H5
[Fault history 5]
-
nOn
-
H6
[Reset fault
history]
0~1
Clears the fault history saved in
H1-5.
0
O
H7
[Dwell
frequency]
0.1~400
[Hz]
When dwell frequency is issued,
the motor restarts to accelerate
after dwell frequency is applied
to the motor during H8- [Dwell
time].
[Dwell frequency] can be set
within the range of F21- [Max
frequency] and F23- [Start
frequency].
5.00
X
H8
[Dwell time]
0~10sec
Sets the time for dwell
operation.
0.0
X
H10 [Skip frequency
select]
0 ~ 1 Sets the frequency range to skip
to prevent undesirable
resonance and vibration on the
structure of the machine.
0 X
H11
1)
[Skip frequency
low limit 1]
0.1~400
[Hz]
Run frequency cannot be set
within the range from H11 to
H16. The frequency values of
the low numbered parameters
cannot be set above those of
the high numbered ones.
Settable within the range of F21
and F23.
10.00
X
H12
1)
[Skip frequency
high limit 1]
15.00
X
H13
1)
[Skip frequency
low limit 2]
20.00
X
H14
1)
[Skip frequency
high limit 2]
25.00
X
H15
1)
[Skip frequency
low limit 3]
30.00
X
H16
1)
[Skip frequency
high limit 3]
35.00
X
H17
[S-Curve
accel/decel start
side]
1~100
[%]
Set the speed reference value
to form a curve at the start
during accel/decel. If it is set
higher, linear zone gets smaller.
40
X
H18
[S-Curve
accel/decel end
side]
1~100
[%]
Set the speed reference value
to form a curve at the end
during accel/decel. If it is set
higher, linear zone gets smaller.
40
X
1)
: Only displayed when H10 is set to 1. # H17, H18 are used when F2, F3 are set to 1 (S-curve).
