12.4 Input/Output phase loss protection
Group Code Parameter Set Range Initial Unit
Function
group 2
H19
[Input/Output phase loss
protection select]
1
0 ~ 3 0

Set H19 value to 1
 Output phase loss: Inverter output is shut off at the event of one or more output phase
loss among U, V and W.
 Set H19 value to 2
 Input phase loss: Inverter output is shut off at the event of one or more input phase loss
among R, S and T. If there is no input phase loss, output is shut off when it is time to replace
DC link capacitor.
 Set H19 value to 3
 Input/output phase loss: Inverter output is shut off at the event of one or more input or
output phases loss among R, S and T or U, V and W If there is no input or output phase loss,
output is shut off when it is time to replace DC link capacitor.
Caution:
Set H33- [Motor rated current] correctly. If the actual motor rated current and the value of H33
are different, output phase loss protection function could not be activated.
H19
[Input/Output
phase loss
protection
select]
Both bars down
Not used
Right hand (low bit) UP
Output phase loss protection
Left hand (high bit) UP
Input phase loss protection
Both bars UP
Input/output phase loss protection
