Santerno Sinus M - 13.7 Parameter code list <Common area>

13-10
Address Parameter Scale Unit
R/W
Data value
0x0010 Output terminal status R
BIT 0~3: Not Used
BIT 4: MO (Multi-Output with OC)
BIT 5~6: Not Used
BIT 7: 3ABC
0x0011
V1
0~3FF
R
Value corresponding to 0V ~ +10V
0x0012 V2 0~3FF R
Value corresponding to 0V ~ –10V input when
Setting FreqMode to 2
0x0013 I 0~3FF R Value corresponding to 0 ~ 20mA input
0x0014 RPM R See Function List.
0x0019
Unit display
R
Not Used
0x001A
Pole number
R
Not Used
0x001B Custom Version
R
Not Used
0x001C Trip information-B R
BIT 0: COM (I/O Board Reset)
BIT 1: FLTL
BIT 2: NTC
BIT 3: REEP
BIT 4~15: Not Used
0x00FF
~
0x0106
Read address register
R
0x00FF: 166
0x0100: 167
0x0101: 168
0x0102: 169
0x0103: 170
0x0104: 171
0x0105: 172 0x0106: 173
0x0107
~
0x010E
Write address register
W
0x0107: 174 0x0108: 175
0x0109: 176
0x010A: 177
0x010B: 178
0x010C: 179
0x010D: 180
0x010E: 181
Note 1) The changed value in Common area affects the current setting but returns to the previous
setting when power is cycled or Inverter is reset. However, changing value is immediately reflected
in other parameter groups even in the case of Reset or Power On/Off.
Note 2) S/W version of Common area is displayed in hexadecimal format, while that of parameter
area (H79) is displayed in decimal format.
