Santerno Sinus M - 7.4 I;O group 2

7-24
LED
display
Parameter name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
I82
[Brake open
current]
0~180
[%]
Sets current level to open the brake.
It is set according to H33’s (motor
rated current) size
50.0
O
I83
[Brake open
delay time]
0~10
[s]
Sets Brake open delay time.
1.00
X
I84
[Brake open FX
frequency]
0~400
[Hz]
Sets FX frequency to open the brake
1.00
X
I85
[Brake open RX
frequency]
0~400
[Hz]
Sets RX frequency to open the brake
1.00
X
I86
[Brake close
delay time]
0~19
[s]
Sets delay time to close the brake
1.00
X
I87
[Brake close
frequency]
0~400
[Hz]
Sets frequency to close the brake
2.00
X
I88
Fire Mode
Frequency
0.0 ~
400.0 Hz
Command frequency when in Fire
Mode
50.0Hz O
I89
PID F/B minimum
scaling factor
0.0 ~
100.0
PID F/B minimum scaling factor 0.0 O
I90
PID F/B
maximum scaling
factor
0.0 ~
100.0
PID F/B maximum scaling factor 100.0 O
I91
A, B Contact type
selection
0
A Contact (Normal open)
0
O
1
B Contact (Normal Close)
I92 MO On delay
0.0~10.0
sec
MO Contact On delay time
0.0 sec X
I93 MO Off delay
0.0~10.0
sec
MO Contact Off delay time
0.0 sec
X
I94
30A,B,C On
delay
0.0~10.0
sec
30 A,B,C Contact On delay time
0.0 sec
X
I95
30A,B,C Off
delay
0.0~10.0
sec
30 A,B,C Contact Off delay time
0.0 sec
X
I96
Fire Mode
Evidence
0 ~ 1
0 : No trip during fire mode
-
-
1 : Trip during fire mode
