MAINTENANCE
5-17SY95C Excavator OMM
Fuse Circuits
Relay Circuits
Contact a SANY dealer for troubleshooting electrical
problems with the machine.
Fuse Amperage Circuit
F1 25A Starting
F2 10A Battery charging
F3 15A Dome light and horn
F4 25A Work light
F5 15A Wiper, washer, and radio
F6 5A HVAC control panel
F7 10A
Global positioning system
(GPS)
F8 20A HVAC system fan
F9 10A Cigarette lighter
F10 10A A/C compressor
F11 25A Monitor controller
F12 25A Fuel pump
F13 20A Unused
F14 15A Unused
Relay Amperage Circuit
K3
12V/35A
Starting
K5 Horn
K6 Work lights
K7 Cold weather starting
K8 Monitor power down
K9 Spare
K12 HVAC system fan
K13 AC compressor
To Next Page
