SPECIFICATIONS
6-3SY95C Excavator OMM
Working Range
0003869
Figure 6-2
Item Description Dimensions
1 Maximum cutting height 23 ft. 10 in. (7260 mm)
2 Maximum dumping height 17 ft. 1 in. (5210 mm)
3 Minimum swing radius 6 ft. 6 in. (1990 mm)
4 Maximum reach at ground level 21 ft. 10 in. (6660 mm)
5 Maximum vertical wall digging depth 10 ft. 1 in. (3080 mm)
6 Maximum digging depth 14 ft. 2 in. (4330)
