Sanyo PLC-XP200L Service Manual

Key No. Part No. Description Key No. Part No. Description
KR7-XP200L00
Electrical Parts List
-128-
L2004 945 086 7560 FILTER,EMI 200MHZ
L2006 945 086 7560 FILTER,EMI 200MHZ
L2007 301 035 4111 MT-GLAZE 0.000 ZA 1/8W
L2821 945 086 7454 FILTER,EMI 50MHZ
L2822 945 086 7454 FILTER,EMI 50MHZ
L3001 945 086 7577 FILTER,EMI 400MHZ
L3002 945 086 7577 FILTER,EMI 400MHZ
L3003 945 086 7577 FILTER,EMI 400MHZ
L3004 945 086 7461 FILTER,EMI 100MHZ
L3006 945 086 7461 FILTER,EMI 100MHZ
L3801 945 086 7454 FILTER,EMI 50MHZ
L3802 945 086 7454 FILTER,EMI 50MHZ
L3803 945 070 3660 INDUCTOR,90 OHM
L3804 945 059 2240 INDUCTOR,2.2U M
L3811 945 086 7454 FILTER,EMI 50MHZ
L3812 945 086 7454 FILTER,EMI 50MHZ
L3813 945 086 7454 FILTER,EMI 50MHZ
L3814 945 086 7454 FILTER,EMI 50MHZ
L3815 945 086 7454 FILTER,EMI 50MHZ
L3816 945 086 7454 FILTER,EMI 50MHZ
L4001 945 086 7577 FILTER,EMI 400MHZ
L4002 945 086 7577 FILTER,EMI 400MHZ
L4003 945 086 7577 FILTER,EMI 400MHZ
L4004 945 086 7577 FILTER,EMI 400MHZ
L4006 945 086 7577 FILTER,EMI 400MHZ
L5001 301 035 4111 MT-GLAZE 0.000 ZA 1/8W
L6001 945 041 1978 INDUCTOR,330 OHM
DIODE
D1001 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D1002 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D1003 307 201 2724 DIODE RB051L-40-TE25
D1004 307 201 2724 DIODE RB051L-40-TE25
D1005 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D1006 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D1007 307 163 0414 DIODE 1SS352-(TPH3)
D1008 307 163 0414 DIODE 1SS352-(TPH3)
D1009 307 163 0414 DIODE 1SS352-(TPH3)
D1010 307 163 0414 DIODE 1SS352-(TPH3)
D1011 307 163 0414 DIODE 1SS352-(TPH3)
D1012 307 163 0414 DIODE 1SS352-(TPH3)
D1013 307 163 0414 DIODE 1SS352-(TPH3)
D1019TM 307 201 2724 DIODE RB051L-40-TE25
D1021 307 163 0414 DIODE 1SS352-(TPH3)
D1022 307 163 0414 DIODE 1SS352-(TPH3)
D2041 307 163 0414 DIODE 1SS352-(TPH3)
D2042 307 163 0414 DIODE 1SS352-(TPH3)
D2821 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D2822 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D2823 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
MISCELLANEOUS
AU2802 945 083 3800 UNIT,REMOCON RECEIVER
IC2821 307 223 7315 PC TLP421F(D4-GB-TP4)
K11A 945 062 3524 SOCKET,D-SUB 15P
K11B 945 078 7998 SOCKET,DVI 24P
K12A 945 036 5202 SOCKET,BNC 5P
K13A 645 092 4200 TERMINAL,BOARD
K14A 945 062 3524 SOCKET,D-SUB 15P
K16A 945 000 2572 JACK,PHONE D8.0
K17A 945 000 2572 JACK,PHONE D8.0
K18A 945 000 2572 JACK,PHONE D8.0
K28D 945 017 1681 JACK,PHONE D3.6
K38A 945 027 8779 PLUG,D-SUB 9P
K38B 945 028 0383 SOCKET,USB 4P
SC1001 945 076 3503 SURGE-ABSORBER
SC1002 945 076 3503 SURGE-ABSORBER
SC1003 945 076 3503 SURGE-ABSORBER
SC1004 945 076 3503 SURGE-ABSORBER
SC1006 945 076 3503 SURGE-ABSORBER
SC1007 945 076 3503 SURGE-ABSORBER
SC1008 945 076 3503 SURGE-ABSORBER
SC2001 945 076 3503 SURGE-ABSORBER
SC2002 945 076 3503 SURGE-ABSORBER
SC2003 945 076 3503 SURGE-ABSORBER
SC2004 945 076 3503 SURGE-ABSORBER
SC2006 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3002 945 076 3503 SURGE-ABSORBER
SC3003 945 076 3503 SURGE-ABSORBER
SC3004 945 076 3503 SURGE-ABSORBER
SC3006 945 076 3503 SURGE-ABSORBER
SC3801 945 076 3503 SURGE-ABSORBER
SC3802 945 076 3503 SURGE-ABSORBER
SC3813 945 076 3503 SURGE-ABSORBER
SC3814 945 076 3503 SURGE-ABSORBER
SC3815 945 076 3503 SURGE-ABSORBER
SC3816 945 076 3503 SURGE-ABSORBER
610 339 9645 ASSY,PWB,R/C FRONT KR7AL
CAPACITOR
C1691 303 281 2415 CERAMIC 0.22U K 16V
C1692 303 155 1612 CERAMIC 33P J 50V
C1693 303 155 1612 CERAMIC 33P J 50V
C2851 303 316 5411 CERAMIC 1U K 10V
C2852 303 392 1215 ELECT 47U M 6.3V
303 387 5310 ELECT 47U M 6.3V
C2854 303 157 6219 CERAMIC 220P K 50V
RESISTOR
R1691 301 255 6513 MT-GLAZE 100 JA 1/10W
R1692 301 255 6513 MT-GLAZE 100 JA 1/10W
R1693 301 255 6513 MT-GLAZE 100 JA 1/10W
R2851 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2852 301 260 4016 MT-GLAZE 68 JA 1/3W
R2853 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
MISCELLANEOUS
AU2801 945 083 3800 UNIT,REMOCON RECEIVER
610 339 9652 ASSY,PWB,COVER SW KR7AL
SW1861 945 063 5176 SWITCH,PUSH 2P-2TX3
610 339 9669 ASSY,PWB,LED KR7AL
CAPACITOR
C6891 303 367 0410 CERAMIC 0.1U K 50V
RESISTOR
R6891 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R6892 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R6893 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R6894 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R6895 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R6896 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
DIODE
D6881 407 263 8218 LED SML022BUT T86
D6882 307 203 7915 LED SML-210MT T86 M
D6883 307 203 7816 LED SML-210LT T86 M

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
