Sanyo PLC-XP200L Service Manual

Key No. Part No. Description Key No. Part No. Description
KR7-XP200L00
-129-
Electrical Parts List
D6884 307 209 7513 LED SML-210YT T86 L
D6885 307 209 7513 LED SML-210YT T86 L
D6892 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
610 339 9676 ASSY,PWB,FILTER SW KR7AL
SW1891 945 063 5176 SWITCH,PUSH 2P-2TX3
PACKING MATERIALS
610 343 3080 CARTON CASE-KR7AL
610 331 3016 CASE ACCESSORY-MZ7A
610 335 0479 CUSHION SPACER-MZ7A
610 334 9275 CUSHION L-KC3A
610 334 9374 CUSHION R-KC3A
645 096 4015 POLY BAG-0750X0600*NC*R8P
ACCESSORIES
OWNER’S MANUAL
610 340 9962 SETUP INST MANUAL-KR7AL
610 341 0159 CD-ROM,OWNERS MANUAL-KR7AL
REMOTE CONTROL
645 097 4069 ASSY,REMOCON CXZH
610 335 0530 RC-BATTERY LID-CXWP
! AC CORD
US 945 064 6363 CORD,POWER-3.0MK,US
EU 945 054 1156 CORD,POWER-3.0MK
UK 945 054 1149 CORD,POWER-3.138MK
MISCELLANEOUS
610 339 2950 ASSY,COVER LENS GH-KC3AL
610 331 7601 ASSY,MOUNTING LENS W-MR3A
910 301 6659 ASSY,SPACER BF-MY8A
945 063 6937 CABLE,USB
945 063 6944 CABLE,USB
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
645 095 9431 CABLE,SRAL

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
