Sanyo PLC-XP200L Service Manual

-53-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
107 CXD3540_VS
0 VS_GSEL 0 ~ 3 0
1 VS_R_RGT 0 ~ 1 1
2 VS_G_RGT 0 ~ 1 0
3 VS_B_RGT 0 ~ 1 1
4 VS_CYCLE 0 ~ 1 0
5 VS_ON 0 ~ 1 0
6 VS_GDAT1 0 ~ 255 0
7 VS_DAT 0 ~ 255 0
8 VS_GDAT3 0 ~ 255 0
9 VS_GDAT2 0 ~ 255 0
108 CXD3540_DSDPOST1
0 HXT_TH4_ON 0 ~ 1 0
1 HXT_TH3_ON 0 ~ 1 0
2 HXT_TH2_ON 0 ~ 1 0
3 HXT_TH1_ON 0 ~ 1 0
4 HXT_ON 0 ~ 1 0
5 HXT_RCALC 0 ~ 1 0
6 HXT_GCALC 0 ~ 1 0
7 HXT_BCALC 0 ~ 1 0
8 HXT_GSEL 0 ~ 1 0
9 HXT_RDAT1 0 ~ 255 0
10 HXT_RDAT2 0 ~ 255 0
11 HXT_RDAT3 0 ~ 255 0
12 HXT_GDAT1 0 ~ 255 0
13 HXT_GDAT2 0 ~ 255 0
14 HXT_GDAT3 0 ~ 255 0
15 HXT_BDAT1 0 ~ 255 0
16 HXT_BDAT2 0 ~ 255 0
17 HXT_BDAT3 0 ~ 255 0
18 HXT_TH1 0 ~ 255 0
19 HXT_TH2 0 ~ 255 0
20 HXT_TH3 0 ~ 255 0
21 HXT_TH4 0 ~ 255 0
22 SEL_MODE2 0 ~ 7 0
200 Option
0 Logo Display Prohibition 0:Menu 1:Forced 0 - 1 0
1 RS232C Baudrate 0: 19200bps 1: 9600bps 0 - 1 0
3 Shipping Set Shipping set when the value is set to 10 0 - 20 0
4 CABLE SW Long Cable 0: Disable 1: Enable 0 - 1 0
5 PW Debug Command Enable
0: Disable (Sanyo Serial Command Enable)
1: Enable (PW Debug Mode)
0 - 1 0
6 Device Refresh Disable 0: Enable 1: Disable 0 - 1 0
8 PJ-NET Hung up check 0: Enable 1: Disable 0 - 1 0
20 Projector Time Reset Reset when the value to set to 10 0 - １0 0
21 Lamp Warning Time (NORMAL) 1-16 4
22 Lamp Warning Time (ECO) 1-16 6
23 Lamp Warning Time (HIGH) not supported 1-16
50 Lamp Replacement Display 1:On 0:Off 0 - 1 1
51 Filter Warning Display 1:On 0:Off 0 - 1 1
52 Lamp Counter Reset Times Read only 0 - 255 0
53 Filter Counter Reset Times Read only 0 - 255 0
54 Factory Default Execute Times Read only 0 - 255 0
55 Motor Operation Stop 0: Enable 1: Disable 0 - 1 0
58 Lamp Go Out Lamp goes out 0 - 1 0
70 ADC Device Select for Analog PC 0 = ISL51002, 1 = PW392 AFE 0 - 1 0
71 ADC Device Select for Component 0 = ISL51002, 1 = PW392 AFE 0 - 1 0
80 Destination Language Set at Shipping 0:English １:Japanese 0 - 1 0
100 Disable Auto Picture Control 0 : Normal operation 1 : Auto Picture Control Off 0-1 Initial: 1 Shipping 0
201 Option (Signal) Not Used
0 FrameLock Option Frame Lock Setting 0: Normal(Auto) 1: OFF 0 - 1 0
1 Dither Enable 0: Disable 1: Enable 0 - 1 0
204 Simulation mode
0 PW392C Enable 0: Off, 1: On 0 - 1 0
1 PW610 Enable 0: Off, 1: On 0 - 1 0

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
