Sanyo PLC-XP200L Service Manual

-52-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
5 VXT_ON 0 ~ 1 0
6 VXT_RDATU1 0 ~ 255 8
7 VXT_RDATU2 0 ~ 255 9
8 VXT_RDATU3 0 ~ 255 22
9 VXT_GDATU1 0 ~ 255 8
10 VXT_GDATU2 0 ~ 255 9
11 VXT_GDATU3 0 ~ 255 22
12 VXT_BDATU1 0 ~ 255 8
13 VXT_BDATU2 0 ~ 255 9
14 VXT_BDATU3 0 ~ 255 22
15 VXT_RDATL1 0 ~ 255 4
16 VXT_RDATL2 0 ~ 255 5
17 VXT_RDATL3 0 ~ 255 11
18 VXT_GDATL1 0 ~ 255 4
19 VXT_GDATL2 0 ~ 255 5
20 VXT_GDATL3 0 ~ 255 11
21 VXT_BDATL1 0 ~ 255 4
22 VXT_BDATL2 0 ~ 255 5
23 VXT_BDATL3 0 ~ 255 11
24 VXT_TH_ON 0 ~ 15 15
25 VXT_TH1 0 ~ 255 30
26 VXT_TH2 0 ~ 255 61
27 VXT_TH3 0 ~ 255 188
28 VXT_TH4 0 ~ 255 229
105 CXD3540_CSC
0 CSC_XH 0 ~ 1 0
1 CSC_ON 0 ~ 1 1
2 CSC_R_GP1 0 ~ 511 324
3 CSC_R_GP2 0 ~ 511 305
4 CSC_R_GP3 0 ~ 511 282
5 CSC_R_GP4 0 ~ 511 259
6 CSC_R_GP5 0 ~ 511 219
7 CSC_R_GP6 0 ~ 511 198
8 CSC_R_GP7 0 ~ 511 172
9 CSC_R_GP8 0 ~ 511 141
10 CSC_G_GP1 0 ~ 511 331
11 CSC_G_GP2 0 ~ 511 309
12 CSC_G_GP3 0 ~ 511 287
13 CSC_G_GP4 0 ~ 511 265
14 CSC_G_GP5 0 ~ 511 231
15 CSC_G_GP6 0 ~ 511 213
16 CSC_G_GP7 0 ~ 511 193
17 CSC_G_GP8 0 ~ 511 166
18 CSC_B_GP1 0 ~ 511 346
19 CSC_B_GP2 0 ~ 511 316
20 CSC_B_GP3 0 ~ 511 290
21 CSC_B_GP4 0 ~ 511 268
22 CSC_B_GP5 0 ~ 511 231
23 CSC_B_GP6 0 ~ 511 209
24 CSC_B_GP7 0 ~ 511 184
25 CSC_B_GP8 0 ~ 511 161
106 CXD3540_SHAD
0 SHAD_GSEL 0 ~ 3 1
1 SHAD_R_CALC 0 ~ 1 1
2 SHAD_G_CALC 0 ~ 1 1
3 SHAD_B_CALC 0 ~ 1 1
4 SHAD_ON 0 ~ 1 0
5 SHAD_R_DAT1 0 ~ 255 37
6 SHAD_R_DAT2 0 ~ 255 18
7 SHAD_R_DAT3 0 ~ 255 12
8 SHAD_G_DAT1 0 ~ 255 37
9 SHAD_G_DAT2 0 ~ 255 18
10 SHAD_G_DAT3 0 ~ 255 12
11 SHAD_B_DAT1 0 ~ 255 0
12 SHAD_B_DAT2 0 ~ 255 18
13 SHAD_B_DAT3 0 ~ 255 12
14 SHAD_COEF 0 ~ 4095 1365

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
