Sanyo PLC-XP200L Service Manual

-56-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
10 Filter 2nd Cartridge Scroll Time 1
2nd Filter Cartridge Used time at N times Scrolling [hour] (N:1-10)
0 - 32767 9999
11 Filter 2nd Cartridge Scroll Time 2 0 - 32767 9999
12 Filter 2nd Cartridge Scroll Time 3 0 - 32767 9999
13 Filter 2nd Cartridge Scroll Time 4 0 - 32767 9999
14 Filter 2nd Cartridge Scroll Time 5 0 - 32767 9999
15 Filter 2nd Cartridge Scroll Time 6 0 - 32767 9999
16 Filter 2nd Cartridge Scroll Time 7 0 - 32767 9999
17 Filter 2nd Cartridge Scroll Time 8 0 - 32767 9999
18 Filter 2nd Cartridge Scroll Time 9 0 - 32767 9999
19 Filter 2nd Cartridge Scroll Time 10 0 - 32767 9999
20 Filter 3rd Cartridge Scroll Time 1
3rd Filter Cartridge Used time at N times Scrolling [hour] (N:1-10)
0 - 32767 9999
21 Filter 3rd Cartridge Scroll Time 2 0 - 32767 9999
22 Filter 3rd Cartridge Scroll Time 3 0 - 32767 9999
23 Filter 3rd Cartridge Scroll Time 4 0 - 32767 9999
24 Filter 3rd Cartridge Scroll Time 5 0 - 32767 9999
25 Filter 3rd Cartridge Scroll Time 6 0 - 32767 9999
26 Filter 3rd Cartridge Scroll Time 7 0 - 32767 9999
27 Filter 3rd Cartridge Scroll Time 8 0 - 32767 9999
28 Filter 3rd Cartridge Scroll Time 9 0 - 32767 9999
29 Filter 3rd Cartridge Scroll Time 10 0 - 32767 9999
248 Filter Scroll Factor (Read only)
0 Filter 1st Cartridge Scroll Factor 1
1st Filter Cartridge Scrolling Factor at N times Scrolling (N:1-10)
0: Manual Scrolling with OSD Menu
1: Auto Scrolling detecting by Filter Clogged
2: Auto Scrolling detecting by specified maximum used time per
a sheet
0 - 255 255
1 Filter 1st Cartridge Scroll Factor 2 0 - 255 255
2 Filter 1st Cartridge Scroll Factor 3 0 - 255 255
3 Filter 1st Cartridge Scroll Factor 4 0 - 255 255
4 Filter 1st Cartridge Scroll Factor 5 0 - 255 255
5 Filter 1st Cartridge Scroll Factor 6 0 - 255 255
6 Filter 1st Cartridge Scroll Factor 7 0 - 255 255
7 Filter 1st Cartridge Scroll Factor 8 0 - 255 255
8 Filter 1st Cartridge Scroll Factor 9 0 - 255 255
9 Filter 1st Cartridge Scroll Factor 10 0 - 255 255
10 Filter 2nd Cartridge Scroll Factor 1
2nd Filter Cartridge Scrolling Factor at N times Scrolling (N:1-10)
0: Manual Scrolling with OSD Menu
1: Auto Scrolling detecting by Filter Clogged
2: Auto Scrolling detecting by specified maximum used time per
a sheet
0 - 255 255
11 Filter 2nd Cartridge Scroll Factor 2 0 - 255 255
12 Filter 2nd Cartridge Scroll Factor 3 0 - 255 255
13 Filter 2nd Cartridge Scroll Factor 4 0 - 255 255
14 Filter 2nd Cartridge Scroll Factor 5 0 - 255 255
15 Filter 2nd Cartridge Scroll Factor 6 0 - 255 255
16 Filter 2nd Cartridge Scroll Factor 7 0 - 255 255
17 Filter 2nd Cartridge Scroll Factor 8 0 - 255 255
18 Filter 2nd Cartridge Scroll Factor 9 0 - 255 255
19
Filter 2nd Cartridge Scroll Factor
10
0 - 255 255
20 Filter 3rd Cartridge Scroll Factor 1
3rd Filter Cartridge Scrolling Factor at N times Scrolling (N:1-10)
0: Manual Scrolling with OSD Menu
1: Auto Scrolling detecting by Filter Clogged
2: Auto Scrolling detecting by specified maximum used time per
a sheet
0 - 255 255
21 Filter 3rd Cartridge Scroll Factor 2 0 - 255 255
22 Filter 3rd Cartridge Scroll Factor 3 0 - 255 255
23 Filter 3rd Cartridge Scroll Factor 4 0 - 255 255
24 Filter 3rd Cartridge Scroll Factor 5 0 - 255 255
25 Filter 3rd Cartridge Scroll Factor 6 0 - 255 255
26 Filter 3rd Cartridge Scroll Factor 7 0 - 255 255
27 Filter 3rd Cartridge Scroll Factor 8 0 - 255 255
28 Filter 3rd Cartridge Scroll Factor 9 0 - 255 255
29
Filter 3rd Cartridge Scroll Factor
10
0 - 255 255
250 Fan Voltage Adjustment
0 Fan 1 Min Adjust (DAC)
DAC Output for Fan Voltage adj.
Adjust Tolerance between DAC and Fan Volt.
*Lamp Mode: Eco
0-255 50 * Fan voltage adj.
1 Fan 1 Max Adjust (DAC) 0-255 220 * Fan voltage adj.
2 Fan 2 Min Adjust (DAC) 0-255 50 * Fan voltage adj.
3 Fan 2 Max Adjust (DAC) 0-255 220 * Fan voltage adj.
4 Fan 3,4 Min Adjust (DAC) 0-255 50 * Fan voltage adj.
5 Fan 3,4 Max Adjust (DAC) 0-255 220 * Fan voltage adj.
6 Fan 5 Min Adjust (DAC) 0-255 50 * Fan voltage adj.
7 Fan 5 Max Adjust (DAC) 0-255 220 * Fan voltage adj.
8 Fan 6 Min Adjust (DAC) 0-255 50 * Fan voltage adj.
9 Fan 6 Max Adjust (DAC) 0-255 220 * Fan voltage adj.
10 Fan 7 Min Adjust (DAC) 0-255 50 * Fan voltage adj.
11 Fan 7 Max Adjust (DAC) 0-255 220 * Fan voltage adj.
12 Fan 8 Min Adjust (DAC) 0-255 50 * Fan voltage adj.
13 Fan 8 Max Adjust (DAC) 0-255 220 * Fan voltage adj.

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
