Sanyo PLC-XP200L Service Manual

-57-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
252 Fan Option
1 Safety Switch Safety Application use 0-6 0
2 Fan Manual Switch Fan Manual SW (0: Auto 1: Manual) 0-1 0
3 Fan1 Manual Voltage
Manual Adjustment Mode (0.1V)
*Effective only when Manual SW is 1.
0-255 100
4 Fan2 Manual Voltage 0-255 100
5 Fan3,4 Manual Voltage 0-255 100
6 Fan5 Manual Voltage 0-255 100
7 Fan6 Manual Voltage 0-255 100
8 Fan7 Manual Voltage 0-255 100
9 Fan8 Manual Voltage 0-255 100
10 Angle Data A Angle Data A (Read only) - -
11 Angle Data B Angle Data B (Read only) - -
12 Press Data Air Pressure Data (Read only) - -
253 Fan Temp Error Setting (Memorized) Normal Ceiling Top Bottom
5 Temp A Warning (Normal) Temp A (Room) to judge the Temp Error at Normal 30-100 47 47 47 47
6 Temp B Warning (Normal) Temp B (Lamp) to judge the Temp Error at Normal 30-100 64 64 64 64
7 Temp C Warning (Normal) Temp C (Panel) to judge the Temp Error at Normal 30-100 59 59 59 59
8 Temp B-A Warning (Normal) Temp B - A (Filter Clogged) to judge the Temp Error at Normal 0-100 50 50 50 50
9 Temp C-A Warning (Normal) Temp C - A (Filter Clogged) to judge the Temp Error at Normal 0-100 23 23 23 23
10 Temp A Warning (Eco) Temp A (Room) to judge the Temp Error at Eco 30-100 47 47 47 47
11 Temp B Warning (Eco) Temp B (Lamp) to judge the Temp Error at Eco 30-100 64 64 64 64
12 Temp C Warning (Eco) Temp C (Panel) to judge the Temp Error at Eco 30-100 59 59 59 59
13 Temp B-A Warning (Eco) Temp B - A (Filter Clogged) to judge the Temp Error at Eco 0-100 50 50 50 50
14 Temp C-A Warning (Eco) Temp C - A (Filter Clogged) to judge the Temp Error at Eco 0-100 23 23 23 23
15 Temp A Warning Offset (Temp)
Temp Warning Offset (Temp)
0-100 13
16 Temp B Warning Offset (Temp) 0-100 13
17 Temp C Warning Offset (Temp) 0-100 13
18 Temp B-A Warning Offset (Temp) 0-100 13
19 Temp C-A Warning Offset (Temp) 0-100 13
20 Temp A Warning Offset (Time)
Time Warning Offset (Time)
0-40 3
21 Temp B Warning Offset (Time) 0-40 3
22 Temp C Warning Offset (Time) 0-40 3
23 Temp B-A Warning Offset (Time) 0-40 3
24 Temp C-A Warning Offset (Time) 0-40 3
Top
45°
315°
135°
225°
Bottom
Ceiling
Normal
254 Fan Control Range Setting (Temp/Spinning) Normal Ceiling Top Bottom
16 Normal Fan Control Min Temp
Temp Sensor Control Start/End Temp St Normal
20-100 31 31 31 31
17 Normal Fan Control Max Temp 20-100 38 38 38 38
18 Normal Fan1 Min
Fan Spinning Set at Normal (Min/Max) (0.1V)
0000-9990 120 120 120 120
19 Normal Fan1 Max 0000-9990 135 135 135 135
20 Normal Fan2 Min 0000-9990 80 80 80 80
21 Normal Fan2 Max 0000-9990 80 80 80 80
22 Normal Fan3,4 Min 0000-9990 70 70 70 70
23 Normal Fan3,4 Max 0000-9990 135 135 135 135
24 Normal Fan5 Min 0000-9990 90 90 90 90
25 Normal Fan5 Max 0000-9990 135 135 135 135
26 Normal Fan6 Min 0000-9990 60 60 60 60
27 Normal Fan6 Max 0000-9990 135 135 135 135
28 Normal Fan7 Min 0000-9990 65 65 65 65
29 Normal Fan7 Max 0000-9990 135 135 135 135
30 Normal Fan8 Min 0000-9990 60 60 60 60
31 Normal Fan8 Max 0000-9990 135 135 135 135
32 Eco Fan Control Min Temp
Temp Sensor Control Start/End Temp St Eco
20-100 31 31 31 31
33 Eco Fan Control Max Temp 20-100 38 38 38 38

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
